CDM Diagnostic Key – Question 2Bugwood Webmaster2020-09-03T14:49:41+00:00 Question 2: Is there dark gray-brown to purplish sporulation on the lower leaf surface? Fig 7. Very light purple-gray sporulation on the underside of a cucumber leaf (Beth K. Gugino, Penn State) Fig 8. Moderate sporulation on the lower leaf surface of pumpkin (Beth K. Gugino, Penn State) Fig 9. Advanced sporulation on the lower leaf surface of cucumber (Beth K. Gugino, Penn State) Yes No Sporulation under magnification Fig 10. CDM hand-lens drawing and description from hand-lens key FIg 11. CDM pathogen sporulation under magnification (Rebecca A. Melanson, Mississippi State University Extension, Bugwood.org) Fig 12. Microscopic view of spores reveals acutely and dischotomously branched sproangiophores bearing lemon-shaped sporangia (Gerald Holmes, Strawberry Center, Cal Poly San Luis Obispo, Bugwood.org)
